OSEEX206-EN
3/10
VALVES SPECIFICATIONS
Water Oil Air, Gas Steam Chemicals Sea water Slurry Negative pressure
SR SH MS type
Valve type SR SH MS
Design 2-way, Full port 2-way, Full port 2-way, Full port
Connection Threaded End Rc Threaded End Rc Threaded End Rc
Fluid
Max pressure 2 MPa 1.4 MPa 2 MPa 3.5 MPa 2.4 MPa
Size [mm] 015 to 020 025 to 040 015 to 032 010 to 025 032 to 050
Material Body SCS14A SCS14A SCS14A
Ball SCS14A SCS14A SCS14A
Seat PTFE F-PTFE R-PTFE
Stem seal Packing F-PTFE R-PTFE R-PTFE
O-ring - FKM (For steam) FKM
PRESSURE & TEMPERATURE RATING
SR SH MS
