ELECTRIC ACTUATOR SPECIFICATIONS
3 way valve: SHUT / Position , OPEN / Position
OPTIONAL PARTS
Specifications Code No. Remarks
Operation mode SW is OFF SHUT , SW is ON OPEN. Nil Mode A (Standard)
SW is ON SHUT , SW is OFF OPEN. Q Mode B
DIMENSIONS
ECR-120 / 360
Parts name
1 Body 6 Limit switch 11 Capacitor
2 Motor cover 7 SW setting cam 12 Capacitor control board
3 Motor 8 Transformer 13 Rubber packing
4 Control board 9 Drive shaft 14
5 Terminal block 10 Manual shaft 15
129
102
15
□
8
2-G1/2
122
60
□
1
2
145
60
PCD.Ø50
4-M6
1
2
12
9
10
7
3
13
4
5
6
8
11
