Nirvana INSTINCT NS230 HL - Rescue Chute Installation; Harness

Last update 23.10.2012
23
48
Securing the V-strut to the
rescue chute with Velcro
49
Fix the rescue chute at the
upper maillon carbiner under
the neoprene seat
50
thread the V-strut through
the harness tunnel …
51
… all the way to the front
rescue chute container
52
attaching the
V-strut to the harness
53
correct position of the rescue
chute
54 56
Setting the angle of the
paramotor
with the upper harness from
the shoulders towards the
main chute buckles. The
correct angle of the
paramotor is 5 to 10 degrees
from the vertical axe.
