Nirvana INSTINCT NS230 HL - Harness

Last update 23.10.2012
26
78
first release the strings
87
released strings
79
then unlock and dismantle
the frame arch and continue
in the opposite procedure as
per picture 45 through to
picture 1
80
first put the harness into the
transport case
81
correct position of the
harness
82
then put the partially
disassembled motor unit into
the transport case
