Appendix D
Fastener Torque Specifications
Correct tightening torque of threaded fasteners is very important to your safety. Always tighten fasteners to the correct torque. In case of
a conflict between the instructions in this manual and information provided by a component manufacturer, consult with your dealer or the
manufacturer’s customer service representative for clarification. Bolts that are too tight can stretch and deform. Bolts that are too loose can
move and fatigue. Either mistake can lead to a sudden failure of the bolt.
Always use a correctly calibrated torque wrench to tighten critical fasteners on your bike. Carefully follow the torque wrench manufacturer’s
instructions on the correct way to set and use the torque wrench for accurate results.
FASTENER COMMON TORQUE
WHEELS Axle Nuts: Front 220 - 260 in-lbs
Rear 260 - 310 in-lb
QR: Force from 90D until full closure
PEDALS 200 - 350in-lbs
SEAT POST CLAMP 35 - 60in-lbs (Seat posts require only minimal tightening to not slip
downward or sideways. Avoid over-tightening)
QR: Force from 90D until full closure
SADDLE CLAMP 175 - 345in-lbs
STEERER CLAMP Threaded Headset Locknut: 200 - 300in-lbs
Stem Binder Bolt Quill Type: 175 - 260in-lbs
Threadless Headset Stem Cap Bolt: 145 in-lbs
Threadless Stem Single Binder Bolt: 100 - 145in-lbs
Threadless Stem Double Binder Bolt: 50 - 85in-lbs
HANDLEBAR CLAMP 6mm Thread Bolt: 120 - 145in-lbs
>6mm Thread Bolt: 175 - 250in-lbs
CONTROL LEVER CLAMPS Road Bike Brake & STI Levers: 53 - 70in-lbs
Flat Bar Brake Levers: 30 - 70in-lbs
Flat Bar Thumb Shifters: 20 - 26in-lbs
Flat Bar Twist Shifters: Shimano 53 - 70 in-lbs; SRAM 17 in - lbs
