1.1.2 Basic Specifications
Printing method Image Area: Dye Diffusion Thermal Transfer
Character Area: Molten Type Thermal Transfer
Protective Layer: Molten Type Thermal Transfer
Printing Media PVC Card (Recommended Card by NISCA)
Size:Conform to JIS X 6301 (ISO standard CR-80)
Thickness:Conform to JIS X 6301(ISO standard CR-80)
Printing
Resolution
300dpi (11.81dots/mm)
Printing
Grayscale
Input:256 grayscale for each colors R,G and B
Output:256 grayscale control for each colors C,M and Y
Printing Size Max. 85.5mm(card longitudinal)
× 54mm(card transverse direction)
Printing
Arrangement Area
Max. Entire area
Printing Speed 45seconds per card excluding communication time at the
whole area printed as mentioned above.
Supply method
and capacity
100 cards(card thickness:0.76mm);supplied automatically
Interface SCSI or USB 2.0 (Fixed in factory)
Power supply AC 100~ 240V 50/60Hz
Power
consumption
120W max.
Equipment
dimensions
421mm(H)×271mm(W)×331mm(D)
(excluding Stack Box)
Equipment weight
13kg:Main body
13.8kg:Including optional magnetic encoder
