INTRODUCTION
HEXPAR 12 is an LED PAR with 6-in-1 RGBAW+UV LEDs that
projects perfectly mixed and nely tunable color.
FEATURES
- 12 x 10W Hex-color RGBAW+UV LED
- Die-cast housing designed for ecient cooling and road-worthy durability
- High-frequency LED modulation for icker-free video playback
- Four selectable dimming curves
- Gel frame and gel frame holder included
- Power In and Out connections for linking mutliple units
- Built-in sound-active and auto (stand-alone) programs
- USB port for optional UFI wi- transceiver for wireless DMX control
- Infrared sensor for optional IR6 remote control
SPECIFICATIONS
Light Source:
Output:
Beam Angle:
Field Angle:
Strobe:
Dimming:
PWM Frequency:
Control modes:
DMX Channels:
Menu:
Mains:
Power:
Power connections:
Power Linking:
Data connections:
Housing:
Finish:
IP rating:
Cooling:
Dimensions:
Weight:
12 x 10W RGBAW+UV LED
lux @ 5m
25°
45°
0 - 30 Hz
0-100% dimming, 4 selectable dimming curves
1200 Hz
DMX, Auto, Sound-Active, Koala wireless DMX
(with optional UFI transceiver), IR (with optional IR6 controller)
6 / 11
4-digit LED display
100 - 240 VAC, 50/60 Hz (auto-ranging)
W
IEC power In/Out
Up to 9 units @ 120V ~ Up to 16 units @ 230V
3-pin XLR In/Out for DMX
Die-cast Aluminium
Matte Black
IP20
Passive
253 x 290 x 98 mm
3.2 KG
4
MASTER/SLAVE OPERATION (via UFI wi- transceiver)
HEX-PAR 12 units can operate in Master/Slave mode wirelessly using the optional UFI wi-
transceiver. The master UFI-enabled unit can be operated in stand-alone mode, with the
UFI set to transmit. The slave units should all be set to slave mode, with the UFI set to
receive.
Note: Slave units should be congured before conguring master unit
Note: All units should be set to same DMX address, mode and UFI channel
Setup as below:
SLAVE UNITS:
Press MENU button until 6-CH or 11-CH is displayed
Press ENTER
Set DMX address to d 1
Set UFI to preferred receiving channel (1-16)
Attach UFI to the HEX-PAR 12's USB port
MASTER UNIT:
Press MENU button until DMX mode is displayed that matches slave conguration
Press ENTER
Set DMX address to d 1
Set to Auto or Sound-Active mode
Set UFI to chosen transmitting channel (1-16)
Attach UFI to the HEX-PAR 12's USB port
13
OPERATING MODE PRIORITY RANK
Higher priority control modes override lower priority modes
1. UFI
2. DMX (wired)
3. Infrared (IR6 remote)
4. Manual (onboard menu)
