Nitec Hex-Par 12 - Overview; Rear View

OVERVIEW
Power Out
Microphone
Display
Safety
Cable
anchor
DMX
In/Out
Power In
UFI Port
Menu
Buttons
Rear View
Adjustment
knob
5
MASTER/SLAVE OPERATION (via DMX cable)
When multiple HEX-PAR 12 units are used together, Master/Slave mode enables the
assignment of one master unit and multiple slave units. The master unit can be operated
in stand-alone mode (i.e., auto program or sound-active mode -- not DMX mode). The
slave units should all be set to slave mode as described below.
Note: Slave units should be congured and connected before linking to master unit
Setup as below:
SLAVE UNITS:
Press MENU button until 6-CH or 11-CH is displayed
Press ENTER
Set DMX address to d 1
Connect DMX cable from master unit to DMX In connector
Link following slave units in similar cable conguration
MASTER UNIT:
Set to Auto or Sound-Active mode
Link to slave units, beginning from the master DMX Out connector
12
