Nitecore i-Generation 21700 User Manual

Power Indication
When the battery is inserted, the head power indicator will flash to show the battery voltage (±0.1V).
When it is disconnected from the power source during the charging process, the tail power indicator will flash to
show the battery voltage (±0.1V).
For example, when the battery voltage is at 4.2V, the power indicator will flash 4 times followed by a 1.5-second
pause and 2 more flashes. Different voltages represent the corresponding remaining battery power levels:
When the light is on, the head power indicator will indicate the remaining battery power.
1. Being steadily turned on indicates that the power is above 50%.
2. Flashing slowly indicates that the power is below 50%.
3. Flashing quickly indicates that the power is below 10%.
Note:
1. When using two CR123/RCR123 in series, the indicator will show the average voltage between the two
batteries.
2. The batteries should be replaced or recharged when the output appears to be dim or the flashlight becomes
unresponsive due to low power.
ATR (Advanced Temperature Regulation)
The integrated ATR technology regulates the output of the P30i according to the working condition and ambient
environment to maintain the optimal performance.
Maintenance
Every 6 months, threads should be wiped with a clean cloth followed by a thin coating of silicon-based lubricant.
