4.4 Fasten the terminal
① Assemble the terminal with the rear case as shown in
Figure 4.3.
Figure 4.3 Assebling with rear case
② Screwing the terminal as shown in Figure 4.4 with the 4
terminal screws supported in the package.
Figure 4.4 Screwing the terminal
