Nittan EVCA-P - Page 12

DW1500110 Rev.K1
Sep 18 2015
12
Figure 10: Correct and incorrect wiring method
For system monitoring － For terminals 1 and 6 do not use looped wire under
terminals. Break wire run to provide monitoring of connections.
! CAUTION
Correct wiring
Incorrect wiring
