Nittan EVCA-P - Section 9 - Specifications

DW1500110 Rev.K1
Sep 18 2015
15
Section 9 – SPECIFICATIONS
Detector Type
Photoelectric smoke detector
LED Visual Indicator
Alarm - Solid red LED
Operating Voltage Range
12VDC to 32VDC peak
System Voltage
24VDC
Stand-by current
30μA. ave. at 24VDC
Alarm Current
68mA. max.
47.5mA at 24VDC
Voltage Ripple
20% maximum
Sensitivity
1.78 %/Ft. to 3.60 %/Ft.
Alarm Characteristics
6VDC in series with 375R between
+ (Terminal 3) and – (Terminal 1, 6) at 25°C
UL Ambient Installation Temperature
0 °C to +49 °C (32 °F to 120 °F)
Operating Temperature
-10 °C to +55 °C (14 °F to 131 °F)
Storage Temperature
-20 °C to +60 °C (-4 °F to 140 °F)
Relative Humidity
≦ RH95% non-condensing
Maximum Quantity per Module
20 units
Start-up Time
20 seconds
Standard
UL 268
Weight
118g (Detector head only)
FOR WARRANTY SERVICE, RETURN TO:
OVERSEAS BUSINESS DIVISION
NITTAN COMPANY, LIMITED
1-54-5 SASAZUKA, SHIBUYA-KU, TOKYO, 151-8535, JAPAN
http://www.nittan.com
