8. PASSI TEST PLUS SOFTWARE
Surfox Passivation Tester can be connected to a pc with USB cable, allowing the download of recorded data.
Before connecting the external unit to the computer, install the software supplied.
8.1 SOFTWARE INSTALLATION
Insert the CD supplied in the computer. The installation will automatically begin through the AutoRun
function. If this feature is disabled, simply open the folder contained on the CD and click on the file "Installer".
Follow the onscreen instructions.
After installation the software will start automatically, confirming the proper installation.
NOTE: in some cases (with Windows 7) a message may appear mentioning to keep the installation as
performed or reinstall according to the Windows settings.
Select “This program installed correctly”
8.2 HARDWARE INSTALLATION
Connect the external unit to the USB port of the computer using the USB cable supplied.
The tester will automatically turn on and driver installation will start.
8.3 SOFTWARE USE
Click on the icon on the desktop or select the program from Start menu to open the program.
Connect the external unit to the USB port using the USB cable supplied.
The tester will automatically turn on and after a few seconds will activate the function keys on the software
screen, in the boxes "Read", "Reset" and "Export"
8.3.1 QUALITY CONTROL DATA DOWNLOAD
To download the Quality Control test, click on "TEST" in the "Read" box.
The transfer of all the tests stored in memory will begin.
8.3.2 DELETING TESTS – USER ID
To delete the tests performed, click on "TEST" in the "Reset" box.
To delete user ID and their passwords from the memory of the unit, click on "USER" in the "RESET" box.
8.3.3 TEST EXPORT
It is possible to export the downloaded data to a .pdf file, to save the document in your files or to print it.
To save the files, click on "PDF" in the "Export" box.
NOTE: Once saved, the file will automatically open in the PDF reader.
