INSTRUCTIONS MANUAL AUTOMATIC FILTERS
FCD-FACD-FFD /DT /DP /DT-DUAL /DP-DUAL
s.r.l.Milano - ITALY Page 17 of 23 fcd-dp_mi-r4.doc – r.4
7.3. How to set day and time of regeneration
The days of the week can be set one by one; they appear on the display in the weekly row: it
is possible to select (visualized the initial letter of the day) or not (visualized the symbol -).
The row and explanation of the symbols that appear on the display are :
M / - T / - W / - T / - F / - S / - S / -
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Sunday
The available digits to set the time are between 00:00 and 23:59; the symbol --:-- indicate
not any ON and/or not any OFF.
The regeneration starts at the time set on the line ON.
The time on the line OFF
MUST BE NECESSARILY SET one minute later than the time
on the line ON.
The programmer allows to set up to 3 regeneration per day (B3-1, B3-2, B3-3).
Proceed as follows to modify :
1. push the button ESC
2. push several times the button until the pointer > points "set param"
3. push the button
OK .
4. push several times the button until the display shows the parameter where to make the
modification (B3 - 1 or other)
5. push the button
OK , the blinking cursor will take place on the line of the days (D)
6. by pushing the button the cursor moves on the positions correspondent to the days of
the week
7. push the button to enable/disable
8. by pushing the button the cursor moves on the several digits of the hours (lines ON and
OFF)
9. when the cursor blinks on the digit to modify, push several times the until the desired
number appears
10. repeat the same operations with other digits, whether required.
11. push the button
OK to confirm the modifications
12. push the button to visualize other parameters which must be modified, and operate as
explained at above points 5 ÷11, or push the button
ESC to leave the modification menu
13. push the button ESC to go back to visualization of service.
WARNING : parameter B3-4 is concerning the pulse function of the parameters
B3-1, B3-2 and B3-3; for a proper working of the whole system, this
parameter must be necessarily set on OFF position.
7.4. How to set time of phases, delay, pressure drop value
Proceed as follows to modify :
1. push the button ESC
2. push several times the button until the pointed > points "set param"
3. push the button
OK .
4. push several times the button until the parameter to modify is shown (B1 or other)
5. push the button
OK .
