INSTRUCTIONS MANUAL AUTOMATIC FILTERS
FCD-FACD-FFD /DT /DP /DT-DUAL /DP-DUAL
s.r.l.Milano - ITALY Page 7 of 23 fcd-dp_mi-r4.doc – r.4
3.4. Dimensions
See DRAWING 1 dimensions
3.5. Weights
MODEL vessel quartz-sand kg
anthracyte shipping on service
kg 04÷07 mm 1÷2 mm 2÷3 mm l (kg) approx. kg approx. kg
FCD 05
135 100 50 35 40(28) 380 600
FCD 08
150 120 60 50 50(35) 460 700
FCD 11
180 200 80 50 70(49) 600 1000
FCD 15
300 250 100 100 100(70) 900 1400
FCD 20
340 300 150 100 130(91) 1050 170
FCD 25
390 400 200 150 150(105) 1350 2100
FCD 30
435 500 200 200 200(140) 1600 2600
FCD 40
550 600 300 200 250(175) 2000 3100
FCD 45
610 700 350 250 300(210) 2300 3600
FCD 50
670 800 400 300 350(245) 2600 4200
FCD 60
740 900 450 350 400(280) 2900 4800
FCD 70
870 1100 500 400 450(315) 3400 5500
FCD 80
1100 1250 600 450 500(350) 4000 6400
MODEL vessel
quartz-sand kg
activated carbon shipping on service
kg
1÷2 mm
l (kg) approx. kg approx. kg
FACD 05
150 30 200(96) 300 500
FACD 08
180 50 280(134) 400 700
FACD 11
300 50 350(168) 560 900
FACD 15
340 75 500(240) 700 1300
FACD 20
390 100 650(312) 900 1600
FACD 25
435 100 800(463) 1000 1900
FACD 30
550 150 1000(480) 1300 2400
FACD 40
670 200 1350(648) 1700 3200
FACD 50
740 250 1600(768) 2000 3700
FACD 60
1100 300 2000(960) 2600 4800
MODEL vessel quartz-sand kg PL
shipping on service
kg
2-3 mm 0.8-1.2 mm
kg approx. kg approx. kg
FFD 04
155 25 200 125 530 750
FFD 06
185 50 300 175 760 1100
FFD 08
300 50 400 250 1100 1600
FFD 10
340 75 525 300 1300 1900
FFD 13
390 100 675 400 1650 2400
FFD 15
435 100 825 475 1900 2800
FFD 19
550 125 1000 575 2350 3500
FFD 23
610 150 1200 700 2800 4100
FFD 30
740 225 1600 950 3700 5500
FFD 35
870 250 1850 1050 4200 6200
FFD 40
1100 275 2100 1200 4900 7200
