INSTRUCTIONS MANUAL AUTOMATIC FILTERS
FCD-FACD-FFD /DT /DP /DT-DUAL /DP-DUAL
s.r.l.Milano - ITALY Page 22 of 23 fcd-dp_mi-r4.doc – r.4

MODEL diaphragm valves distributor
V1 V2 V3 V4 V5 number/type
FCD 05
1"NC 1¼"NO 1"NC 1¼"NO 1"NC
6 x B144
FCD 08
1"NC 1½"NO 1¼"NC 1½"NO 1¼"NC
6 x B175
FCD 11
1"NC 1½"NO 1¼"NC 1½"NO 1¼"NC
6 x B175
FCD 15
1"NC 2"NO 1½"NC 2"NO 1½"NC 30 plate
FCD 20
1"NC 2"NO 1½"NC 2"NO 1½"NC 36 plate
FCD 25
1"NC 2½"NO 2"NC 2½"NO 2"NC 42 plate
FCD 30
1¼"NC DN80NO 2½"NC DN80NO 2½"NC 56 plate
FCD 40
1¼"NC DN80NO 2½"NC DN80NO 2½"NC 68 plate
FCD 45
1¼"NC DN80NO 2½"NC DN80NO 2½"NC 84 plate
FCD 50
1½"NC DN100NO DN80NC DN100NO DN80NC 87 plate
FCD 60
1½"NC DN100NO DN80NC DN100NO DN80NC 104 plate
FCD 70
1½"NC DN100NO DN80NC DN100NO DN80NC 118 plate
FCD 80
1½"NC DN100NO DN80NC DN100NO DN80NC 142 plate
MODEL diaphragm valves distributor
V1 V2 V3 V4 V5
number/type
FACD 05
1"NC 1¼"NO 1"NC 1¼"NO 1"NC
6 x B175
FACD 08
1"NC 1½"NO 1¼"NC 1½"NO 1¼"NC
6 x B175
FACD 11
1"NC 1½"NO 1¼"NC 1½"NO 1¼"NC 30 plate
FACD 15
1"NC 2"NO 1½"NC 2"NO 1½"NC 36 plate
FACD 20
1"NC 2½"NO 2"NC 2½"NO 2"NC 42 plate
FACD 25
1"NC 2½"NO 2"NC 2½"NO 2"NC 56 plate
FACD 30
1¼"NC DN80NO 2½"NC DN80NO 2½"NC 68 plate
FACD 40
1¼"NC DN80NO 2½"NC DN80NO 2½"NC 87 plate
FACD 50
1½"NC DN100NO DN80NC DN100NO DN80NC 104 plate
FACD 60
1½"NC DN100NO DN80NC DN100NO DN80NC 142 plate
MODEL diaphragm valves distributor
V1 V2 V3 V4 V5
number/type
FFD 04
1"NC 1¼"NA 1"NC 1¼"NA 1"NC
6 x B175
FFD 06
1"NC 1½"NA 1¼"NC 1½"NA 1¼"NC
6 x B175
FFD 08
1"NC 1½"NA 1¼"NC 1½"NA 1¼"NC 30 piastra
FFD 10
1"NC 1½"NA 1½"NC 1½"NA 1½"NC 36 piastra
FFD 13
1"NC 2"NA 1½"NC 2"NA 1½"NC 42 piastra
FFD 15
1¼"NC 2"NA 2"NC 2"NA 2"NC 56 piastra
FFD 19
1¼"NC 2½"NA 2½"NC 2½"NA 2½"NC 68 piastra
FFD 23
1¼"NC 2½"NA 2½"NC 2½"NA 2½"NC 84 piastra
FFD 30
1½"NC DN80NA 2½"NC DN80NA 2½"NC 104 piastra
FFD 35
1½"NC DN80NA 2½"NC DN80NA 2½"NC 118 piastra
FFD 40
1½"NC DN100NA DN80NC DN100NA DN80NC 142 piastra
