Scan it, for more
Information
Version 11/2020
PSE10L-C-SMS-002-EN
INSTRUCTION MANUAL
Electric Stacker PSE10L-C
WARNING
Do not use the electric truck before reading and
understanding these operating instructions.
NOTE:
● Please check the designation of your present type
at the last page of this document as well as on the
ID-plate.
● Keep for future reference.
This truck should be used in factories,
tourist attractions and playgrounds only.

Table of Contents

Questions and Answers

  • J
    Jackson TorresAug 14, 2025
    What to do if my Noblelift Forklifts stacker cannot be operated?
    • V
      Victor Smith IIAug 14, 2025
      If your Noblelift Forklifts stacker isn't working, there could be several reasons. Ensure the battery is fully charged and the main power plug is removed from the socket after charging. Check that the battery is correctly connected and that all fuses are in good condition, replacing them if necessary. Verify that the truck is powered on by checking the emergency switch, key switch, and other switches. Also, make sure you're following the correct sequence of operations: move the tiller bar to the braking position, then back to the operating position, before using the accelerator.
  • E
    Eric GrossAug 17, 2025
    Why Noblelift Forklifts loads cannot be lifted?
    • P
      ppollardAug 18, 2025
      If your Noblelift Forklifts cannot lift loads, it might be due to several reasons. First, ensure that the load weight is within the rated capacity of the truck. If the load is not too heavy, check if the battery is discharged and charge it if necessary. Finally, inspect the lifting fuse and replace it if it's faulty.
  • K
    Kelly LynchAug 20, 2025
    What to do if my Noblelift Forklifts stacker travels very slowly?
    • E
      elijah08Aug 20, 2025
      If your Noblelift Forklifts stacker is moving very slowly, you should first check the battery status using the discharge indicator. If the battery is low, charge it. Also, inspect the electromagnetic brake to ensure it is not engaged. Finally, check the tiller cables and connectors for any disconnections or damage.
  • K
    Kathy GonzalezAug 25, 2025
    What to do if my Noblelift Forklifts stacker starts up suddenly?
    • B
      Bryan JimenezAug 25, 2025
      If your Noblelift Forklifts stacker starts up suddenly, it could be due to a damaged controller, which would need replacing. Alternatively, the accelerator might not be returning to its neutral position, requiring repair or replacement.
  • S
    Susan GordonAug 27, 2025
    What to do if Noblelift Forklifts loads cannot be lowered?
    • S
      Sandra BarronAug 27, 2025
      If loads cannot be lowered on your Noblelift Forklifts, it could be due to dirty oil blocking the control valve. Check the hydraulic oil, clean the control valve, and replace the hydraulic oil if needed. Another possible cause is a malfunctioning lowering electromagnetic valve; check or replace it.
  • S
    Sarah CarrollAug 31, 2025
    What to do if my Noblelift Forklifts stacker only travels in one direction?
    • X
      xcollinsAug 31, 2025
      If your Noblelift Forklifts stacker only moves in one direction, the accelerator or its connectors may be damaged. You should check both the accelerator and the connectors for any issues.
  • P
    Paige SchroederSep 3, 2025
    What to do if hydraulic oil level is too low in Noblelift Forklifts?
    • S
      Steven CruzSep 3, 2025
      If the hydraulic oil level is too low in your Noblelift Forklifts, you should check and refill the hydraulic oil.
  • A
    Aaron BerrySep 6, 2025
    What to do for oil leakage in Noblelift Forklifts?
    • C
      Carl BeckerSep 7, 2025
      To address oil leakage in your Noblelift Forklifts, check and repair the seal performance of the oil hoses and/or cylinder.
  • S
    Samuel WalkerSep 10, 2025
    What to do for oil suction failure in Noblelift Forklifts?
    • M
      mparkerSep 10, 2025
      To solve the oil suction failure in your Noblelift Forklifts, reduce the oil quantity.

Summary

Foreword

Description of Electric Stacker

Overview of Main Parts

Identifies and lists the main physical parts of the electric stacker.

Main Technical Data

Provides detailed technical specifications and dimensions for the stacker.

Safety Devices and Warning Labels

Explains various safety decals, warning labels, and their meanings.

Identification Plate

Details the information found on the truck's identification plate.

Correct Application

Modification

Details regarding alterations to the truck and warranty implications.

Warnings, Risks, and Safety Instructions

General Prohibitions (DO NOT)

Lists actions and conditions that must be avoided during operation.

Operational Safety Guidelines

Outlines essential safety practices and environmental considerations for operation.

Commissioning, Transporting, Decommissioning

Commissioning

Steps and data required for initial setup and operation of the stacker.

Hoisting and Transportation

Instructions for safely hoisting, transporting, and securing the stacker.

Decommissioning

Procedures for storing, preparing for long-term storage, or final disposal.

Daily Inspection

Pre-Operation Checks

Details essential checks to perform before operating the stacker daily.

Operation Instructions

Parking

Instructions on how to safely park the electric stacker.

Residual Lift Diagram

Explanation and use of the residual lift diagram for load capacity.

Lifting and Lowering

Procedures for safely lifting and lowering loads and forks.

Driving

Instructions for operating the stacker, including inclines and controls.

Steering and Braking

How to steer the stacker and the different braking mechanisms.

Malfunctions and Emergency

Steps to take in case of malfunctions or emergencies, including using the emergency button.

Battery Charging and Replacement

Battery Replacement

Step-by-step guide for replacing the stacker's batteries.

Battery Indicator

Explanation of the battery indicator display and its symbols.

Battery Charging

Instructions for charging the stacker's battery using the built-in charger.

Regular Maintenance

Maintenance Precautions

Safety measures and general advice before starting maintenance tasks.

Maintenance Checklist

A detailed checklist of maintenance tasks and their recommended intervals.

Lubricating Points

Identifies specific points on the stacker requiring lubrication.

Hydraulic Oil Check and Refill

Procedure for checking and refilling the hydraulic oil, including type and viscosity.

Electrical Fuses

Steps to inspect and check the electrical fuses for proper function.

Protective Mesh Removal

Instructions for safely removing and reassembling the protective mesh.

Trouble Shooting

Common Issues and Solutions

Guidance on diagnosing and resolving common operational problems.

Wiring; Circuit Diagram

Electrical Circuit Diagram (Lead-Acid)

Detailed electrical circuit diagram for lead-acid battery models.

Electrical Circuit Diagram (Lithium)

Detailed electrical circuit diagram for Lithium battery models.

Hydraulic Circuit Diagram

Diagram illustrating the hydraulic system of the stacker.

Noblelift PSE10L-C Specifications

General IconGeneral
Load Capacity1000 kg
Overall Width800 mm
Battery Voltage24 V
Drive TypeElectric
Load Center Distance600 mm
Fork Length1070 mm
Power TypeBattery
Tire TypePolyurethane
Lift Motor Power2.2 kW
Travel Speed5.5 km/h
Mast TypeDuplex
Travel Speed (loaded/unloaded)5.5 km/h
