OPERATION
2
Typhoont EV 1592/1512 (03–03)
This manual is furnished with each new model. It
provides necessary operation and maintenance
instructions and an illustrated parts list.
Read this manual completely and understand the
machine before operating or servicing.
When ordering replacement parts, use the Parts Lists
section in this manual. Before ordering parts or
supplies, be sure to have your machine model number
and serial number handy. Parts and supplies may be
ordered by phone or mail from any Authorized Service
Center or Distributor.
This machine will provide excellent service. However,
the best results will be obtained at minimum costs if:
S The machine is operated with reasonable care.
S The machine is maintained regularly - per the
maintenance instructions provided.
S The machine is maintained with manufacturer’s
supplied or equivalent parts.
MACHINE DATA
Model No.-
Install. Date -
Serial No.-
Please fill out at time of installation for future
reference.
E1999, 2000, 2003 Tennant Company Printed in the U.S.A.
Nobles is a registered United States trademark of Tennant Company.
Typhoon is a United States trademark of Tennant Company.
TABLE OF CONTENTS (ESPAÑOL ÍNDICE....12)
SAFETY PRECAUTIONS 3. . . . . . . . . . . . . . . . . . . .
GROUNDING INSTRUCTIONS 4. . . . . . . . . . .
WARNING LABEL 4. . . . . . . . . . . . . . . . . . . . . . . . . .
MACHINE COMPONENTS 5. . . . . . . . . . . . . . . . . . .
MACHINE SETUP 5. . . . . . . . . . . . . . . . . . . . . . . . . .
SQUEEGEE KIT ATTACHMENT (OPTIONAL) 5
ACCESSORY TOOL ATTACHMENT 6. . . . . . .
MACHINE OPERATION 7. . . . . . . . . . . . . . . . . . . . .
WET VACUUMING 7. . . . . . . . . . . . . . . . . . . . . .
SQUEEGEE WET VACUUMING: 7. . . . . . . . . .
ACCESSORY TOOL WET VACUUMING: 8. . .
DRAINING RECOVERY TANK 8. . . . . . . . . . . .
DRY VACUUMING 8. . . . . . . . . . . . . . . . . . . . . . .
MACHINE MAINTENANCE 9. . . . . . . . . . . . . . . . . .
STORING MACHINE 9. . . . . . . . . . . . . . . . . . . . .
RECOMMENDED STOCK ITEMS 9. . . . . . . . . . . . .
TROUBLE SHOOTING 10. . . . . . . . . . . . . . . . . . . . . .
SPECIFICATIONS 11. . . . . . . . . . . . . . . . . . . . . . . . . .
ELECTRICAL DIAGRAMS 22. . . . . . . . . . . . . . . . . . .
PARTS LIST 23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
STANDARD FLOOR TOOL KIT 23. . . . . . . . . . .
MACHINE PARTS DIAGRAM 24. . . . . . . . . . . . .
OPTIONS 26. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
WET/DRY TOOL KIT 26. . . . . . . . . . . . . . . . . . . . .
WET PICK–UP TOOL KIT 27. . . . . . . . . . . . . . . .
SQUEEGEE KIT BREAKDOWN 28. . . . . . . . . . .
