2600classic RM-340/RM-341
Page
(15) ISSUE 3
Service Manual Level 1&2
ASSEMBLY13.
1. Nokia 2600 Assembly hints. 2. You need the Nokia Standard Toolkit version 2.
3. Slot the connector Through the recess of the
ENGINE MODULE.
4. Close the connector. Mind the correct positioning of the
connector before going on.
5. Slot the ex foil into the connector. 6. Now align the ex foil evenly and close the connector.
7. Tighten the screws with a torque of 15Ncm in the order
shown.
