Nokia 2660 RM-292 - Page 19

19
CONFIDENTIAL
Copyright © 2007 NOKIA. All rights reserved.
2660 RM-292/RM-293
Page (30) ISSUE 1
Service Manual Level 1&2
19. Press the end of the PWB FLEX (FPC B2B ASSY) into the
direction shown.
20. Turn around the Upper Block and the C-COVER and remove
the end of the PWB FLEX (FPC B2B ASSY).
21. Now, separate the C-COVER from the Upper Block.
22. Push out the HINGE MODULE from the B-COVER...
23. ...and remove it. The disassembly procedure is now
nished.
