Nokia 2680 slide Service Manual

2680 Slide RM-392, RM-393
Service Manual Level 1&2
ISSUE 1
Confidential
Copyright @ 2008 NOKIA. All rights reserved.
6
4. ESD PROTECTION
Nokia requires that service points have sufficient ESD protection (against
static electricity) when servicing the phone.
Any product of which the covers are removed must be handled with ESD
protection. The SIM card can be replaced without ESD protection if the
product is otherwise ready for use.
To replace the covers ESD protection must be applied.
All electronic parts of the product are susceptible to ESD. Resistors, too, can
be damaged by static electricity discharge.
All ESD sensitive parts must be packed in metallised protective bags during
shipping and handling outside any ESD Protected Area (EPA).
Every repair action involving opening the product or handling the product
components must be done under ESD protection.
ESD protected spare part packages MUST NOT be opened/closed out of an
ESD Protected Area.
For more information and local requirements about ESD protection and ESD
Protected Area, contact your local Nokia After Market Services representative.

Nokia 2680 slide Specifications

General

Display type	TFT
Display resolution	128 x 160 pixels
Display number of colors	65536 colors
Internal memory	32 MB
Rear camera	Yes
Rear camera resolution	640 x 480 pixels
Networking type	EGSM/GSM
Operating frequency	850/900/1800/1900 MHz
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Ringer type	Polyphonic
Form factor	Slider
Personal info management (PIM)	Alarm clock, Calculator, Calendar, Notes, Stopwatch, To-do list
Product color	Pink
Battery type	BL-4S
Talk time (2G)	3.43 h
Battery capacity	860 mAh
Standby time (2G)	419 h
Bluetooth version	2.0+EDR
Data network	EDGE, GPRS

Weight and Dimensions

Depth	47 mm
Width	99 mm
Height	15.5 mm
Weight	75.7 g
