Nokia 3220 - Technical Information

Nokia 3220 User Guide 61 Copyright © 2004 Nokia
Reference information
• TECHNICAL INFORMATION
Feature Specification
Dimensions
Width 44.2 mm
Height 104.5 mm
Depth 18.7 mm
Weight 86 g with BL-5B Li-Ion Battery
Wireless networks
Nokia 3220: EGSM 900 and GSM 1800 and 1900 networks
Nokia 3220b: GSM 850, 1800, and 1900 networks
Size (volume) 70 cm
3
Frequency range (Tx)
GSM 850: 824–849 MHz (for RH-49)
EGSM 900: 880–915 MHz (for RH-37)
GSM 1800: 1710–1785 MHz (for RH-49 and RH-37)
GSM 1900: 1850–1910 MHz (for RH-49 and RH-37)
Frequency range (Rx)
GSM 850: 869–894 MHz (for RH-49)
EGSM 900: 925–960 MHz (for RH-37)
GSM 1800: 1805–1865 MHz (for RH-49 and RH-37)
GSM 1900: 1930–1990 MHz (for RH-49 and RH-37)
Tx output power 2 W (max)
Battery voltage 3.7 V dc
Number of channels 299
Memory size
16 MB flash memory, approximately 2 MB available
to user
Operating
temperature
Between 59°F and 77°F (15°C and 25°C).
