Nokia 3650 Service Manual

nokia
CONNECTING PEOPLE
PAGE 8 (27) Approval 4.0
Nokia Mobile Phones Customer Care EMEA
DJk
Technical Services, Repair Concepts Confidential 11.11.2003
SOLDERING COMPONENTS ONLY FOR LEVEL 2
ITEM/
CIRCUIT REF.
QTY PART NO PART NAME
F380 1 5119019 SM FUSE F 1.5A 32V 0603
G190 1 4700129 BATTERY LITHIUM 0.1MAH 3V
S130 1 5209001 SM SW TACT SPST 12V 50MA SIDE KEY
VARIANT PARTS 3650
ITEM/
CIRCUIT REF.
QTY PART NO PART NAME
I001 1 9458717 A COVER BLUE
I001 1 9458531 A COVER YELLOW
I001 1 9458528 A COVER STAY SILVER
I002 1 9790661 KEYMAT LATIN
1 9458715 C COVER BLUE
1 9458523 C COVER YELLOW
1 9458521 C COVER STAY SILVER
VARIANT PARTS 3660
ITEM/
CIRCUIT REF.
QTY PART NO PART NAME
I001 1 9453606 A COVER RED
I001 1 9453607 A COVER BLUE
I002 1 9791139 KEYMAT LATIN
I002 1 9791140 KEYMAT RUSSIAN
I002 1 9791141 KEYMAT GREEK
I002 1 9791144 VODAFONE KEYMAT
1 9453605 C COVER RED
1 9453604 C COVER BLUE
Service Manual 3650 / 3660 Level 1&2 Copyright 2003 © Nokia Corporation

Nokia 3650 Specifications

General

Display Type	TFT, 4096 colors
Display Size	2.1 inches
Resolution	176 x 208 pixels
Internal Storage	4 MB
Card Slot	MMC
Video	Yes
Battery Type	Removable Li-Ion 850 mAh battery (BL-5C)
Dimensions	130 x 57 x 26 mm
Weight	130 g
Status	Discontinued
Network	GSM 900 / 1800 / 1900
EDGE	No
SIM	Mini-SIM
Downloadable themes	Yes
Phonebook	Yes
Call records	Yes
Alert types	Vibration; Downloadable polyphonic ringtones
Loudspeaker	Yes
3.5mm jack	No
WLAN	No
Bluetooth	Yes
GPS	No
Radio	No
USB	Pop-Port
Messaging	SMS, MMS, Email
Java	Yes, MIDP 1.0
Predictive text input	Yes
Organizer	Yes
Infrared port	Yes
Talk time	Up to 4 h
Operating System	Symbian OS v6.1, Series 60 v1.0 UI
Main Camera	VGA
Announced	2002, September
GPRS	Class 4
Browser	WAP 1.2.1, XHTML
Games	Yes
Colors	Blue
CPU	104 MHz ARM 9
