Nokia FastMile 4G Receiver Product Overview Functional overview
Issue: 01 DRAFT 3TG-00386-ABAA-TCZZA 43
DRAFT
Figure 10 Remote management of the Nokia FastMile 4G Receiver through an ACS
TR-069
ACS
Radio
basestation
Residential
gateway
PoE
Injector
LTE
1
Gbps
Ethernet
Wi-Fi or
Ethernet
WiFi or Ethernet
connectivity to
end-user devices
that are using
IPTV, internet,
and VoIp
28817
Core
IPTV
Internet
VoIP
Nokia
FastMile
G Receiver
4
