Nokia 5230 Serivce Manual

Nokia 5230
RM-588 / RM-593 / RM-594 / RM-629
Service Manual Level 1&2
6 Confidential • Copyright © 2010 NOKIA • All rights reserved Version 8.0
3. ESD PROTECTION
Nokia requires that service points have sufficient ESD protection (against
static
electricity) when servicing the phone.
Any product of which the covers are removed must be handled with ESD
protection. The SIM card can be replaced without ESD protection if the product
is otherwise ready for use.
To replace the covers ESD protection must be applied.
All electronic parts of the product are susceptible to ESD. Resistors, too, can be
damaged by static electricity discharge.
All ESD sensitive parts must be packed in metallized protective bags during
shipping and handling outside any ESD Protected Area (EPA).
Every repair action involving opening the product or handling the product
components must be done under ESD protection.
ESD protected spare part packages MUST NOT be opened/closed out of an ESD
Protected Area.
For more information and local requirements about ESD protection and ESD
Protected Area, contact your local Nokia After Market Services representative.

Nokia 5230 Specifications

General

Operating System	Symbian OS v9.4, Series 60 rel. 5
Camera	2 MP
Internal Storage	70 MB
Expandable Storage	microSD, up to 16 GB
Battery	Removable Li-Ion 1320 mAh battery (BL-5J)
Weight	115 g (4.06 oz)
Network Technology	GSM / HSPA
Launch Date	2009, August
Status	Discontinued
SIM	Mini-SIM
CPU	434 MHz ARM 11
Camera Video	480p@30fps
Sound Loudspeaker	Yes
Audio Jack	3.5 mm
Bluetooth	2.0, A2DP
Radio	Stereo FM radio, RDS
USB	microUSB 2.0
Stand-by	Up to 432 h (2G) / Up to 432 h (3G)
Talk time	Up to 7 h (2G) / Up to 4 h 30 min (3G)
Music play	Up to 33 h
Display	3.2 inches, 360 x 640 pixels
Dimensions	111 x 51.7 x 15.5 mm
Memory Card Slot	microSD, up to 16 GB
GPS	Yes, with A-GPS
Colors	Black, White, Red, Pink, Blue
