Nokia 5230 User Manual

Contacts bar
To add a contact to the home screen, in the home screen, select > Options >
New contact, and follow the instructions.
Antenna locations
Your device may have internal and external antennas. Avoid touching the antenna
area unnecessarily while the antenna is transmitting or receiving. Contact with
antennas affects the communication quality and may cause a higher power level
during operation and may reduce the battery life.
Cellular antenna
GPS antenna
Bluetooth antenna
© 2010 Nokia. All rights reserved. 31
To communicate with a contact, select the contact and from the following:
Call
the contact.
Send a message to the contact. Modify the contact's details.
Refresh the contact's web feeds.
To view past communication events with a contact, select the contact. To view the
details of a communication event, select the event.
To close the view, select
.

Nokia 5230 Specifications

General

Operating System	Symbian OS v9.4, Series 60 rel. 5
Camera	2 MP
Internal Storage	70 MB
Expandable Storage	microSD, up to 16 GB
Battery	Removable Li-Ion 1320 mAh battery (BL-5J)
Weight	115 g (4.06 oz)
Network Technology	GSM / HSPA
Launch Date	2009, August
Status	Discontinued
SIM	Mini-SIM
CPU	434 MHz ARM 11
Camera Video	480p@30fps
Sound Loudspeaker	Yes
Audio Jack	3.5 mm
Bluetooth	2.0, A2DP
Radio	Stereo FM radio, RDS
USB	microUSB 2.0
Stand-by	Up to 432 h (2G) / Up to 432 h (3G)
Talk time	Up to 7 h (2G) / Up to 4 h 30 min (3G)
Music play	Up to 33 h
Display	3.2 inches, 360 x 640 pixels
Dimensions	111 x 51.7 x 15.5 mm
Memory Card Slot	microSD, up to 16 GB
GPS	Yes, with A-GPS
Colors	Black, White, Red, Pink, Blue
