20
CONFIDENTIAL
Copyright © 2007 NOKIA. All rights reserved.
N5700 RM-230 / RM-302
Page (53) ISSUE 2
Service Manual Level 1&2
7. Always use a new UPPER IHF GASKET.
8. Insert the IHF SPEAKER, paying attention to the right position
of the spring contacts.
9. Align the HINGE MECHANICAl ASSY with the UPPER BLOCK...
10. ...and assemble the unit starting on the shown side.
11. Do the same on the other side.
12. Set the torque driver to the correct torque...
