N5700 RM-230 / RM-302
Page (53) ISSUE 2
Service Manual Level 1&2
13. ...and tighten the screws in the order shown.
14. Tighten the HINGE screws to the same torque in the order
shown.
15. Always use new SCREW STICKERS when assembling the
unit.
16. Cover the HINGE screws as shown.
17. Always use a new SIDE CONNECTOR TAPE...
18. ...and position it exactly into its place.
