22
CONFIDENTIAL
Copyright © 2007 NOKIA. All rights reserved.
N5700 RM-230 / RM-302
Page (53) ISSUE 2
Service Manual Level 1&2
19. Close the LCD connector.
20. Place the LCD into the FRAME UPPER ASSY, starting on the
shown side.
21. Gently t the FRAME LCD ASSY. Take care to the LCD ex...
22. ...and secure the FRAME LCD into its place.
23. Fit the JOYSTICK COVER. Note its correct position.
24. Place the KEYMAT MENU.
