28
CONFIDENTIAL
Copyright © 2007 NOKIA. All rights reserved.
N5700 RM-230 / RM-302
Page (53) ISSUE 2
Service Manual Level 1&2
19. Lift the CAMERA housing from its position.
20. Remove the PWB MODULE.
21. Separate the D-COVER MUSIC from the UPPER BLOCK.
22. Remove the IHF SPEAKER.
23. Remove the adhesive resiodues.
24. Remove the Microphone.
To Next Page
