Nokia 5730 Xpress Music

Nokia 5730 XpressMusic RM-465
Service Manual Level 1&2
16 Confidential  Copyright © 2009 NOKIA  All rights reserved Version 1.0 ISSUE 1
25) Use the SS-93 to lift the engine module and
carefully separate it from the B-COVER.
26) Remove the FLEX PLANE from the engine board
by opening a small clip with the dental tool.
27) Open the DYNAMIC FLEX connector with the SRT-
6. Be careful not to damage the connector.
28) Separate the engine board and the SLIDE
MODULE.
29) Remove the FLEX SLIDER using the SS-93. 30) Open the connector of the DYNAMIC FLEX and
separate it from the SLIDE MODULE. Be careful to not
to damage the connector.
