Nokia 6021 Service Manual

nokia
CONNECTING PEOPLE
PAGE 10 (22) Approved 1.0
CMO Operations & Logistics
MGR
WW Service Solutions & Development
Bochum / Germany CONFIDENTIAL 17.3.2005
Test Pins
for Flash Adapter SF-17
RJ-66
Soldering Jig
Lead-free Solder Wire
Mandatory for lead-free products (Level 2 only).
0772040 NMP Standard Toolkit
 NOKIA opening tool SRT-6 NOKIA No. 0770431
 Tonichi torque driver NOKIA No. 6901525

Hoya micro fibre cloth MX304

Dastex gloves S, M, XL

Artilux goggles AH166

Wera bit T5 867/4TX 5x50
 Wera 867/4 6IP; 50mm (Torx 6 PLUS®)
 Wera bit T6 867/4TX 6x50
 Wera 867/1 5IP; 25mm (Torx 5 PLUS®)
 Wera bit T6 PLUS® 867/4TX 6IP

Facom side cutter 416E
 Facom T5 driver SP.14032
 Facom T6 driver SP.14033
 Facom slot screwdriver AEF. 2x35.E

Wetec tweezers 7abb SA-ESD
 Wetec tweezers 22 SA-ESD
 Wetec tweezers 13 SA-SMD ESD
 Wetec tweezers PSF SA-ESD
 Wetec ESD brush E1211

Kaiser Fototechnik airbrush 6315
 Wetec dental tool DEM83266/0

RS Components Scissors 323-5732
Service Manual 6021 Level 1&2 Copyright © 2005 NOKIA Corporation. All rights reserved.

Nokia 6021 Specifications

General

Network Technology	GSM
2G bands	GSM 900 / 1800 / 1900
GPRS	Class 10
Status	Discontinued
Weight	88 g (3.10 oz)
SIM	Mini-SIM
Display Type	CSTN, 65K colors
Call records	20 dialed, 20 received, 20 missed calls
Battery	Removable Li-Ion 760 mAh battery (BL-5B)
Vibration	Yes
Messaging	SMS, MMS, Email
Browser	WAP 2.0/xHTML
Radio	No
Clock	Yes
Alarm	Yes
Java	Yes, MIDP 2.0
Push to Talk	Yes
Presence enhanced contacts	Yes
Organizer	Yes
Infrared port	Yes
EDGE	Class 6
Announced	2005
Dimensions	106 x 44 x 20 mm, (4.17 x 1.73 x 0.79 in)
Display Resolution	128 x 128 pixels
Phonebook	500 entries
Ringtones	Polyphonic, MP3
Games	Yes
Colors	Black
