Nokia 6021 Service Manual

nokia
CONNECTING PEOPLE
PAGE 9 (22) Approved 1.0
CMO Operations & Logistics
MGR
WW Service Solutions & Development
Bochum / Germany CONFIDENTIAL 17.3.2005
7. SERVICE TOOLS
FLS-4S incl. ACF-8, Driver and User Guide
Dongle and flash device incorporated into one package,
developed specifically for POS use.
ACF-8
Universal Power Supply is used to power FLS-4S.
Internal Battery BL-5B
Inserted under the back cover, this Li-Ion 760 mAh battery
provides power in a lightweight package.
Travel Charger ACP-12
Small and lightweight charger for fast charging of your phone
battery.
Headset HS-5
An easy and convenient handsfree solution with remote control.
XCS-1
Service Cable is used to connect FLS-4S to SF-17 .
SF-17
POS Flash Adapter is used in POS (Point of Sales) environment for
software updating. It provides controlled supply voltage and
necessary connections between the phone and the Flash Device.
It substitutes for the phone’s standard battery during the
software update.
Service Manual 6021 Level 1&2 Copyright © 2005 NOKIA Corporation. All rights reserved.

Nokia 6021 Specifications

General

Network Technology	GSM
2G bands	GSM 900 / 1800 / 1900
GPRS	Class 10
Status	Discontinued
Weight	88 g (3.10 oz)
SIM	Mini-SIM
Display Type	CSTN, 65K colors
Call records	20 dialed, 20 received, 20 missed calls
Battery	Removable Li-Ion 760 mAh battery (BL-5B)
Vibration	Yes
Messaging	SMS, MMS, Email
Browser	WAP 2.0/xHTML
Radio	No
Clock	Yes
Alarm	Yes
Java	Yes, MIDP 2.0
Push to Talk	Yes
Presence enhanced contacts	Yes
Organizer	Yes
Infrared port	Yes
EDGE	Class 6
Announced	2005
Dimensions	106 x 44 x 20 mm, (4.17 x 1.73 x 0.79 in)
Display Resolution	128 x 128 pixels
Phonebook	500 entries
Ringtones	Polyphonic, MP3
Games	Yes
Colors	Black
