Nokia 6288 Service Manual

Training and Vendor Development
CMO Operations & Logistics
Multimedia Creation & Support CONFIDENTIAL
26.Feb.2007
10
Service Manual 6288 RM-78/RM-268
Copyright © 2006-2007 NOKIA Corporation. All rights reserved.
Approved 1.0
MGR
Page
(24)
FLS-5 incl. ACF-8, Driver and User Guide
Dongle and flash device incorporated into one package, developed
specifically for POS use.
ACF-8
Universal Power Supply is used to power FLS-5.
Travel Charger AC-4
Small and lightweight charger with smaller charging plug to charge
your phone battery fast.
Internal Battery BP-6M
Inserted under the back cover, this Li-Ion battery provides power in a
lightweight package.
Headset HS-23
Small and lightweight stereo headset with handsfree functionality,
volume control, Push to talk support, and comfortable earpieces for
listening to the FM radio or MP3 player in compatible phones.
SS-51
Camera removal tool for VGA camera (Frontside)
SS-45
Camera removal tool for 2 Megapixel camera (Backside)
SERVICE TOOLS8.

Nokia 6288 Specifications

General

Display type	TFT
Display diagonal	2.2 \
Display resolution	240 x 320 pixels
Display number of colors	262144 colors
Internal memory	152 MB
Flash card support	Yes
Compatible memory cards	miniSD
Rear camera resolution	1600 x 1200 pixels
Interface	Pop-Port, PC Suite
Networking type	GSM, EDGE, UMTS
Playback formats	MP3, MP4, AAC & eAAC+
Operating frequency	900/1800/1900/2100 MHz
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Ringer type	Polyphonic
Polyphonic rings quantity	64
Form factor	Slider
Personal info management (PIM)	Alarm clock, Calculator, Calendar
Product color	Black
Talk time (2G)	4.5 h
Standby time (2G)	280 h
Bluetooth version	2.0+EDR
Data network	3G, EDGE, GPRS
Mobile network generation	3G

Weight and Dimensions

Depth	21 mm
Width	46 mm
Height	100 mm
Weight	115 g
