Nokia 6288 Service Manual

Training and Vendor Development
CMO Operations & Logistics
Multimedia Creation & Support CONFIDENTIAL
26.Feb.2007
2
Service Manual 6288 RM-78/RM-268
Copyright © 2006-2007 NOKIA Corporation. All rights reserved.
Approved 1.0
MGR
Page (24)
CHANGE HISTORY
Status Version No. Date Comments
Draft 0.1 8.Feb.2007 Initial draft
Approved 1.0 26.Feb.2007 Approval
Page
TABLE OF CONTENTS
INTRODUCTION 3
GENERAL REPAIR INFORMATION
4
PATHFINDER FOR WORKSHOP STAFF
5
EXPLODED VIEW
6
SPARE PARTS OVERVIEW
7
GENERAL RECYCLING RECOMMENDATION
8
NOKIA ONLINE (NOL)
9
SERVICE TOOLS 1
0
SW-UPDATE 1
2
DISASSEMBLY INSTRUCTION (UPPER PART) 1
3
DISASSEMBLY INSTRUCTION (LOWER PART) 1
6
MAIN DOMESHEET EXCHANGE INSTRUCTIONS 1
9
LEGEND FOR QUICK TROUBLE SHOOTER 2
0
QUICK TROUBLE SHOOTER PART 1 2
1
QUICK TROUBLE SHOOTER PART 2 2
2
QUICK TROUBLE SHOOTER PART 3 2
3
QUICK TROUBLE SHOOTER PART 4 2
4
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.

Nokia 6288 Specifications

General

Display type	TFT
Display diagonal	2.2 \
Display resolution	240 x 320 pixels
Display number of colors	262144 colors
Internal memory	152 MB
Flash card support	Yes
Compatible memory cards	miniSD
Rear camera resolution	1600 x 1200 pixels
Interface	Pop-Port, PC Suite
Networking type	GSM, EDGE, UMTS
Playback formats	MP3, MP4, AAC & eAAC+
Operating frequency	900/1800/1900/2100 MHz
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Ringer type	Polyphonic
Polyphonic rings quantity	64
Form factor	Slider
Personal info management (PIM)	Alarm clock, Calculator, Calendar
Product color	Black
Talk time (2G)	4.5 h
Standby time (2G)	280 h
Bluetooth version	2.0+EDR
Data network	3G, EDGE, GPRS
Mobile network generation	3G

Weight and Dimensions

Depth	21 mm
Width	46 mm
Height	100 mm
Weight	115 g
