Nokia 6300b RM-222 User Manual

Training and Vendor Development
CMO Operations & Logistics
Multimedia Creation & Support CONFIDENTIAL
12.Sept.2007
14
Service Manual 6300 RM-217/ 6300b RM-222
Copyright © 2006-2007 NOKIA Corporation. All rights reserved.
Approved 4.0
MGR
Page (33)
19. Unlock both metal clips of the UI SHIELD.
20. Carefully unlock the ex connector of the LCD MODULE.
21. Peel up the protective lm.
22. Now separate the parts as shown.
23. Cover the display with a lm again.
24. Remove the MICROPHONE and the DC JACK.
