Nokia 6300b RM-222 User Manual

Training and Vendor Development
CMO Operations & Logistics
Multimedia Creation & Support CONFIDENTIAL
12.Sept.2007
15
Service Manual 6300 RM-217/ 6300b RM-222
Copyright © 2006-2007 NOKIA Corporation. All rights reserved.
Approved 4.0
MGR
Page (33)
25. Carefully lever out the EARPIECE ASSEMBLY.
26. Carefully unlock the clip securing the PLASTIC CHAMBER.
27. Now remove it.
28. The IHF SPEAKER is not glued and can be removed easily.
29. Carefully release the clips of the LED- and the SIDE
WINDOW.
30. The POWER- and the VOLUME KEY can be removed easily.
WWW.PCBOOK.IR

Nokia 6300b RM-222 Specifications

General

Brand	Nokia
Model	6300b RM-222
Category	Cell Phone
Language	English
