Nokia 6500 Classic - Get Started; Install SIM and Battery; Charge the Battery

12
CONFIDENTIAL
Copyright © 2007 NOKIA. All rights reserved.
6500 classic RM-265
Page (23) ISSUE 1
Service Manual Level 1&2
13. Open the clip on the top with the dental pick.
14. Now, continue on the other side of the LCD FRAME.
15. Place the LCD FRAME and the LCD MODULE on the UI
interface.
16. Undo the ve screws in the order shown....
17. ...and remove them.
18. Take special care to the electric components on the AV FLEX.
