NOT CHARGING ( NOTHING HAPPENS IF CHARGER IS CONNECTED )
First of all : Always Check the mechanical condition of all connectors and connections
Not charging
Check voltage level at R104-
if it is higher than 0,4V when
charger is connected
Check/change N100
Check/change R102/103/104,
F100, X101/102/200,
N101, C101/144,R101 (soldering,
electrical and mechanical
condition)
PCB faulty
lower 0,4V
OK
>0,4V
notOK
