CONFIDENTIAL 5 (30)

NSE-5

Service & Analysis Center Europe Repairhints Version 1.0 Approved

SACE AMS Training Group 30.07.2000

Repairhints_nse5_002508 Checked by:

AMS TRAINING GROUP

Approved by:

SACE

INSERT SIMCARD

Insert SIMcard

Check soldering and

contacts of X100

Check signals at X100,

(see next page)

pin1 -SIMclk;

pin2 -SIMrst;

pin3;5 -VSIM;

pin6 -SIMdata

Change N100

Check lines to GND at

C116/129/130/131.

Values must be >100k

Also check R120

D300 or PCB

faulty

Resolder or

change X100

not OK
