Nokia 7110 Manual

CONFIDENTIAL 7 (30)
NSE-5
Service & Analysis Center Europe Repairhints Version 1.0 Approved
SACE AMS Training Group 30.07.2000
Repairhints_nse5_002508 Checked by:
AMS TRAINING GROUP
Approved by:
SACE
SIMCARD NOT ACCEPTED
"SIMCard not accepted" appears on
LCD
Use WinTesla to open
"QuickInfo"- window.
Compare shown SIMlock data with the
listed entries of the respective product code
Rewrite SIMlock settings with NOKIA
SECURITY PASSWORD or send phone to
SACE. If SIMlock is corrected or inactive, but
fault stays on- change COBBA* and rewrite
SIMlock data.
SIMlock is OK.
If the MSIN data field is closed to a special IMSI
number range, only the operator is authorized to
open the SIMlock.
See General SB 065
OK
notOK
*NOTE: If COBBA or D301 was changed, SIMlock & IMEI
data must be rewrite.
Also realign RX/TX values, especially TX I/Q !
Change D301 if is
permitted to you to
rewrite IMEI
Send Phone to SACE if
it is not permitted to
you to rewrite the IMEI
notOK notOK

Nokia 7110 Specifications

General

Release Date	1999
Announced	1999
Status	Discontinued
Network	GSM 900 / 1800
Weight	141 g
Display Type	Monochrome graphic
Display Size	96 x 65 pixels
Display Lines	5 lines
Talk Time	up to 4 h 30 min
Infrared Port	Yes
SIM	Mini-SIM
Messaging	SMS
Radio	No
Games	Yes
Java	No
Dimensions	125 x 53 x 24 mm
Data	HSCSD
WAP	Yes (1.1)
Colors	Silver
