Nokia 7210 Service Manual

PAGE 5 (19) Approved 1.0
Nokia Mobile Phones Customer Care E&A
SQX 00444-en MWy
Technical Services, Repair Concepts Confidential 25.09.2002
2. SPARE PARTS LIST
SPARE PARTS
ITEM/
CIRCUIT REF.
QTY PART NO PART NAME
I003
1 9517173 DISPLAY SHIELD DMC04171 NHL-4
I004
1 4850261 LCD MODULE 130X130 COG COLOURSTN
I005
1 0201827
TK4 UI BOARD MODULE (7210)
I005
1 0201909
TK7 UI BOARD MODULE (6610)
I006
1 9467076 LCD FRAME DMC03935 NHL-4
I007
1 9470283 SPEAKER FOAM TAPE
I008
1 5140251 SPEAKER105+-3DB32R D8.1X2.25 PICO
I009
1 5140263 MIC+BOOT ASSY -42+-3DB D7.7X3MM
I010
6 6290107 SCREW 1.8X7.0 FE T6+ DMD05791 BLK
I012
2 5400263 ANTENNA POGO PIN L=8.7MM D=2.1MM
I013
1 9452236 VOLUME KEY DMD07492 NHL-4
I014
1 9452235 IR WINDOW DMD07490 NHL-4
I015
1 5400243 CONN DC-JACK 3.5MM 3POL SPR 90DEG
I016
1 6800057 VIB.MOTOR ASSY 1.3 VDC 11000 RPM
I017
1 9470205 RELEASE BUTTON NHL-4
I018
1 9510845 SPRING NHL-4
I019
1 9452237 POWER KEY DMD07491 NHL-4
I020
1 XXXXXXX SPEAKER HF 69+-2DB8R D16X4.36
I022
1 0660264
ANTENNA INT ANTENNA EGSM/PCN/PCS (7210)
I022
1 0660267
ANTENNA INT ANTENNA EGSM/PCN/PCS (6610)
SOLDERING COMPONENTS ONLY FOR LEVEL 2
ITEM/
CIRCUIT REF.
QTY PART NO PART NAME
S300 1 5209001 SM SW TACT SPST 12V 50MA SIDE KEY
S301 1 5209001 SM SW TACT SPST 12V 50MA SIDE KEY
S302 1 5409235 SM TACT SW TRAV 0.2 4.1X3.55X1.75
F100 1 5119019 SM FUSE F 1.5A 32V 0603
G300 1 4700131 CELL CAPACITOR 0.01MAH 3V3
V101 1 4864573 LED CL19WBVA WHITE
V102 1 4864573 LED CL19WBVA WHITE
V103 1 4864573 LED CL19WBVA WHITE
V104 1 4864573 LED CL19WBVA WHITE
V105 1 4864573 LED CL19WBVA WHITE
V106 1 4864573 LED CL19WBVA WHITE
