PAGE 9 (19) Approved 1.0
Nokia Mobile Phones Customer Care E&A
SQX 00444-en MWy
Technical Services, Repair Concepts Confidential 25.09.2002
4. INFRARED GONOGO TEST
You need another infrared device (e.g. 6310i) to do a GoNoGo test. The infrared windows
of the devices must be directed to each other and should have a distance of approximate
15 cm.
Test unit Reference Unit
o
From Home Menu, select
key. This displays Phonebook entries. If phone and
SIM memory is empty, create one new entry.
o
Choose one phonebook entry and select
o
Select
o
Select
o
Select
o
Sending in progress, please wait
o
If sending of business card fails
, make sure again, that infrared
windows are directed to each other. If infrared is activated in reference device
,
try again sending.
o
Test was successful, if you get this message on receiver device
.
You will
not
get a confirmation on sender device.
o
Press
for Home Menu
Service Manual 7210/6610 Level 1&2 Copyright 2002 © Nokia Corporation
