Flash concept with FPS-10
Figure 4 Basic flash concept with FPS-10
Type Description
Product specific devices
FS-85 Flash adapter
Other devices
FPS-10 Flash prommer box
PKD-1/PK-1 SW security device
SS-46 Interface adapter
PC with Phoenix service software
Cables
XCS-4 Modular cable
CA-35S Power cable
USB cable
RM-352; RM-354
Service Devices and Service Concepts
Issue 1 COMPANY CONFIDENTIAL Page 2 –17
Copyright © 2008 Nokia. All rights reserved.
