3.3.3 Commercial Cellular Antennas
Table 12 lists the commercial cellular antennas that are available from and approved
by Nokia for use with the 7705 SAR-Hm and 7705 SAR-Hmc.
3.3.3.1 Outdoor 2G/3G/4G Omni-directional Antenna
The Outdoor 2G/3G/4G omni-directional Antenna (3HE12343AA) is a MIMO
omni-directional LTE antenna that operates at two frequency ranges, 695 to 960
MHz and 1700 to 2700 MHz with gain of 2 dBi and 3dBi respectively. Impedance is
50 Ω. The antenna is equipped with two N-Type (female) connectors.
Installation instructions, a mounting bracket, U-bolts, and fastening hardware for
mounting the antenna on a mast up to 2.5 in. (63.5 mm) O.D. are shipped with the
antenna. See Outdoor 2G/3G/LTE Omni-directional Antenna Specifications and
Outdoor 2G/3G/4G Omni-directional Antenna Installation Overview for more
information.
Table 12 Carrier Wireless Commercial Antenna Options
Nokia Part
Number
Description Comments
3HE12343AA Outdoor 2G/3G/4G omni-directional
Antenna
Omni-directional antenna with mounting bracket kit.
See Outdoor 2G/3G/4G Omni-directional Antenna.
3HE12344AA Outdoor 2G/3G/4G directional
Antenna
Directional antenna with mounting bracket kit. See
Outdoor 2G/3G/4G Directional Antenna.
3HE12371AA Indoor LTE omni-directional Antenna See Indoor LTE Omni-directional Antenna.
