Nokia 7705 SAR-Hm User Manual

SAR-Hm and SAR-Hmc Chassis Installation Guide 7705 SAR-Hm and 7705 SAR-Hmc Overview
3HE 17810 AAAA TQZZA © 2022 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
75
3.4 GNSS Components
All 7705 SAR-Hm and 7705 SAR-Hmc variants have a GNSS receiver. Table 13 lists
the chassis models and the supported GNSS systems and frequencies.
Refer to the GNSS Installation Guide
, located in the Nokia Documentation Center,
for more information on antenna offerings, cable installation kits, and installation.
Table 13 Carrier Wireless Module Variants and Supported GNSS Systems and Frequencies
Nokia Part
Number
Carrier Wireless Module Variant Supported GNSS System and Frequency
3HE11600AA 7705 SAR-Hm 3G/LTE North America and
EMEA
• GPS (1575.42 MHz)
• GLONASS (1602 MHz)
3HE11602AA 7705 SAR-Hm 3G/LTE APAC and ROW
3HE12472AA 7705 SAR-Hmc NA
3HE12473AA 7705 SAR-Hmc NA Variant 2
3HE12474AA 7705 SAR-Hmc B31 (EMEA/CALA)
3HE12475AA 7705 SAR-Hmc B87 (EMEA/CALA)
3HE12477AA 7705 SAR-Hmc EMEA/APAC
