Nokia C1-02 Service Manual

Nokia C1-
02
RM-643 / RM-644
Service Manual Level 1&2
15 Confidential | Copyright © 2010 Nokia | All rights reserved Version 1.0
19) Remove the ENGINE BOARD.
20) Use the sharp end of the SS-93 to release the
EARPIECE / SPEAKER / VIBRA.
21) Remove it with the tweezers. 22) Release the DC JACK with the DC plug.
23) Remove it with the tweezers. 24) Use the sharp end of the SS-93 to release the
ANTENNA MODULE clip and then use the flat end of
the SS-93 to release the bottom end of the ANTENNA
MODULE.

Nokia C1-02 Specifications

General

Display	TFT, 65K colors
Battery	Removable Li-Ion 1020 mAh battery (BL-5C)
Weight	78 g (2.75 oz)
SIM	Mini-SIM
Network	GSM 900 / 1800
Bluetooth	No
Radio	FM radio
USB	No
Status	Discontinued
Stand-by	Up to 504 h
Talk time	Up to 10 h 40 min
Alert types	Vibration, MP3 ringtones
Loudspeaker	Yes
3.5mm jack	Yes
WLAN	No
Browser	WAP 2.0/xHTML
Games	Yes
Camera	No
Dimensions	108 x 45 x 13.8 mm
Announced	2010, June
Colors	Black, Red, Blue
Messaging	SMS, MMS, Email
Java	Yes
