Installation
14
Remote control button
The remote control button should be located so that it is within easy
reach of the user. However, ensure that it is placed so that the cable for
connection to the handsfree unit can be mounted. A suitable mounting
position for the remote control button may be on the console between
the front seats.
To mount the remote control button, use the hook and loop tape
provided. First detach the two parts of the pads from each other. Attach
the pad with the loops first: peel off the protective sheet from the
adhesive side (A) and attach the pad to the desired location in your car
(B). Make sure that the surface where you intend to attach the pad is dry
and free from dirt and dust.
Attach the pad with the hooks next: peel off the protective sheet from
the adhesive side (C) and attach the pad to the underside of the remote
control button.
Press the remote control button (D) firmly onto the loop pad mounted in
the car.
Loudspeaker
To ensure good acoustic quality, mount the loudspeaker so that it is
pointed in the user’s direction. We recommend that you mount the
loudspeaker a minimum distance of 1 metre away from the microphone
to avoid feedback.
The Advanced Car Kit also supports connection to a compatible car radio
system. If yo wish to use the car radio installed in your vehicle with the
Advanced Car Kit for audio output, ask your service technician for
professional advice.
Connect the loudspeaker or a compatible car radio system to the
"SPEAKER" output.
A
B
C
D
