Nokia E51 Service Manual

8
CONFIDENTIAL
Copyright © 2007 NOKIA. All rights reserved.
E51 RM-244
Page
(13) ISSUE 1
Service Manual Level 1&2
SERVICE TOOLS9.
FLS-5 incl. ACF-8, Driver and User
Guide
Dongle and flash device incorporated
into one package, developed specifi-
cally for POS use.
ACF-8
Universal Power Supply is used to
power FLS-4S.
Travel Charger AC-4
Small and lightweight charger for
fast charging of your phone battery.
DKE-2
Service Cable to connect the PC with
the Mini USB connector.
SS-102
Camera removal tool.
RJ-175
Soldering Jig
0772040
NMP Standard Toolkit (V2)
For more informations refer to the
Service Bulletin (SB-011) on NOKIA On-
line.
Supplier or manufacturer contacts for
tool re-order can be found in “Recom-
mended service equipment” docu-
ment on NOKIA Online.
Internal Battery BP-6MT
Inserted under the back cover, this
Li-Ion battery provides power in a
lightweight package.

Nokia E51 Specifications

General

Display diagonal	2 \
Display resolution	240 x 320 pixels
Display number of colors	16.78 million colors
User memory	4096 MB
Internal memory	130 MB
Flash card support	Yes
Rear camera resolution (numeric)	2 MP
Networking type	GSM
Playback formats	MP3/MPEG-4/AAC/eAAC+/WMAAMR-NB/AMR-WB
Operating frequency	850/900/1800/1900 MHz
USB 2.0 ports quantity	1
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Ringer type	Polyphonic
Form factor	Bar
Personal info management (PIM)	Calendar, To-do list
Product color	Silver
Battery type	BP-6MT
Talk time (2G)	4.4 h
Battery capacity	1050 mAh
Standby time (2G)	312 h
Bluetooth version	2.0+EDR
Data network	GPRS

Weight and Dimensions

Depth	114.8 mm
Width	46 mm
Height	12 mm
Weight	100 g
