7. Position it over the ex foil assemblies, mind the guides.
8. Push it down slightly.
9. Bend over this contact foil and x it.
10. Lift up the SLIDE MODULE ASSEMBLY and turn it. Remove this
protecting lm.
11. Position it as shown, smooth it down evenly.
12. Mind the alignment tabs.
